The RF Series is a simple but very useful tool to create your LED projects with stunning RGB effects. An intuitive handheld remote controller also allows the endusers to access and change the light settings.
- Color selection via RGB color wheel
- Program, program speed and dimmer selection
- Remote control unit can be linked with additional RGB receivers
- 13 fixed programs for recall
- RJ45 sockets for Master / Slave function with other units to realise big installations
Technical Data
ELECTRICAL CHARACTERISTICS | |
---|---|
Max. load per Channel | 3x 60W @ 12V |
Max. load per Channel | 3x 120W @ 24V |
Max. load per Channel | 3x 240W @ 48V |
Total maximum load | max. 720W |
Input voltage | DC 12-24 V |
Input current | max. 15A |
Connection possibility | Screw terminals & RJ45 sockets |
Frequency | 2.4 GHz |
Transmission range | approx. 20m |
ABSOLUTE MAXIMUM RATINGS | |
Working temperature | -20˚C – +50˚C |
Storage temperature | -20˚C – +50˚C |
IP rating | IP-20 |
GENERAL CHARACTERISTICS | |
Channels | 3 |
Material | PC housing |
Color | Black |
Mounting | Screw holes & DIN-rail adapter |
DIMENSIONS & WEIGHT | |
Length | 115 mm |
Width | 57 mm |
Height | 25 mm |
Weight | 0.14 kg |
